Size	20 mm to 90 mm
Standard	EN 50262 : 1999
Application	Outdoor or Indoor for use with all types of Unarmoured Cable
Function	Provide Seal on Outer Sheath of the Unarmoured Cable
Material	Brass BS 2874 CZ121 Pb3
Optional Threads	METRIC, NPT, BSP, PG or as specified
Finish	Brass Finish, Nickel Finish, Chrome Finish or as specified
Operating Temp.	Standard seals -200 C to +800 C
Accessories	Matching Accessories available like PVC Shrouds, Lock Nuts, Earth Tags, Reducers, Adaptors, etc. as per the requirement

TECHNICAL DATA
SIZE	THREAD SIZE 'C'		MINIMUM LENGTH OF THREAD 'D'	CABLE RANGE
	MM	INCH		MAX 'A'	MAX 'B'
A2 20S	20	3/4	15	10.80	8.80
A2 20L	20	3/4	15	14.70	11.40
A2 25S	25	1	15	16.00	13.00
A2 25L	25	1	15	20.30	17.30
A2 32S	32	1.1/4	15	23.00	20.00
A2 32L	32	1.1/4	15	26.20	24.20
A2 40S	40	1.1/2	20	29.00	26.00
A2 40L	40	1.1/2	20	34.00	29.50
A2 50S	50	2	20	41.00	33.00
A2 50L	50	2	20	45.00	38.00
A2 63S	63	2.1/2	20	51.50	44.00
A2 63L	63	2.1/2	20	56.50	50.00
A2 75S	75	3	20	63.20	56.00
A2 75L	75	3	20	68.50	62.00

Also available in Kit Packaging and also as per the specification
